Organic Fertilizer Granulator Machine

Product Introduction:

High-humidity material compost granulating machine is also known as wet stirring tooth granulator, internal rotation stirring tooth granulator. Wet organic fertilizer granulator is widely used in granulation of organic fertilizer. Due to high granulation rate, stable operation, sturdy and durable, long service life, and stable base design, it is chosen as an ideal product by majority of users. Wet granulator has various specifications such as 400, 600, 800, 1000, 1200, 1500, etc., also can be customized according to user needs.

Stirring teeth manure granules granulator is suitable for organic fertilizer raw materials: livestock and poultry manure, composting fertilizer, green manure, sea manure, cake fertilizer, peat, soil miscellaneous fertilizer. qualified granulation rate of this machine > 90%, adapt to variety of different formulas, compressive strength of end product is higher than disc granulator and drum granulator, large pellet rate < 15%, particle size uniformity can be adjusted according to user's requirements through machine's stepless speed regulation function. This machine is suitable for direct granulation of organic fertilizer after fermentation, which save drying process and greatly reduce manufacturing cost.

Product Feature:

※ Principle is simple, granulation speed is fast.

※ No need to add binder when granulating.

※ Granulation quality is high. This machine is especially suitable for granulation of light fine powder materials. Particles is finer of powder materials, better pellet sphericity.

※ Wide range of materials sources, such as livestock and poultry manure, compost manure, green manure, sea manure, cake manure, peat, soil miscellaneous manure, three wastes, and microorganisms.

※ Granules are firm and can be screened after granulation. Organic matter after fermentation does not need to be dried, which greatly reduce manufacturing cost. Moisture content of raw materials can be 20-40%.

※ Compared with natural agglomeration granulation equipment (such as disc granulator, drum granulator), the particle size distribution is concentrated and easy to control.

※ High efficiency, easier to meet requirement of mass production.

※ Spherical particles have no acute angle after granulation, pulverization rate is extremely low.

※ Particles produced are spherical. Content of organic matter can reach 100%, realizing the granulation of pure organic matter.

Structure Overview:

New type organic fertilizer granulator is composed of motor, transmission, rotor, cylinder and frame.

1. It adopt Y series national standard motor, which has characteristics of strong power, energy saving, reliable quality and overload operation.

2. Interior of reducer is made of special material and processed by special technology. It has characteristics of high bearing capacity, stable operation, durable parts and reliable operation.

3. Rotor is divided into three parts:

① Shaft ② Stirring tooth ③ Stirring tooth head.

The shaft is divided into three sections: ① mixing section ② granulation section ③ polishing section

Big shaft is made of special material and specially made. Stirring teeth are made of special material, hard and wear-resistant, length can be adjusted. Stirring tooth head is made of alloy steel cutter head.

4. Cylinder is divided into three parts: feed mixing section, granulation section and polishing section.

Working Principle:

1.Stirring tooth granulator utilize high-speed rotating mechanical stirring force and resulting aerodynamic force to make fine powder material continuously realize processes of mixing, granulation, spheroidization, densification in machine, so as to achieve granulation purpose. Shape of the particle is spherical, size is generally between 1.5~4mm, granulation rate of 2~4.5mm particle is ≥90%. Particle diameter can be properly adjusted through mixing amount of materials and spindle speed. Usually, the lower the mixing amount, the higher the speed, smaller the particle, conversely, the larger the particle.

2. Tooth-stirring granulator process fermented organic raw materials into granules. Compared with disc granulator, yield is higher, granules are uniform, smooth, high-strength and low-moisture. Temperature after forming is about 30℃. After the fermented raw materials are crushed, they are mixed by mixer with water content of material is 35%-40%. After entering stirring tooth granulator, spherical particles can be processed. Bigger water content cause bigger pellet, smaller water content cause smaller pellet. It uses characteristic of organic fertilizer raw material embedded in each other under certain effect to produce round, smooth, high-strength particles. Necessary additives and adhesives can also be added to further improve product quality.

Technical Parameters:

Henan Lofty Fertilizer Machinery Co., Ltd. was established in 2001 year, located in Xingyang --- the hometown of machinery in Henan province, 15 kilometers from west of Zhengzhou.

Main products include: organic fertilizer, compound fertilizer, BB fertilizer, blended fertilizer complete production line with capacity 10,000--200,000 tons/year, non-drying extrusion production line, high-humidity materials drying and fermentation equipment such as chicken manure. We obtained 13 national utility model patent certificates, passed ISO9001 quality system certification and environmental management system certification; won honors such as "Contract-honoring and Promise-keeping Demonstration Enterprise", "AAA-Level Integrity Enterprise", "3.15 Product Quality Trustworthy Unit" and so on.

International Cooperation

Our company follows the concept of "service marketing" and cooperates with National Agricultural Technology Research Institute for many times, specializing in development of agricultural environmental protection technology and reducing waste for reuse. We have strong technical force, high-quality R&D, design and manufacturing teams. For a long time, we have been committed to the production of organic fertilizer production lines, compound fertilizer production lines and BB fertilizer production lines, providing customers with process design, equipment manufacturing, installation&commissioning etc one-stop services. Our equipment across the country and is exported to Southeast Asia, Africa, South America, European countries.

Henan Lofty Fertilizer Equipment Co., Ltd. has always been market-oriented, seeks development by innovation, strives for survival by quality, and takes perfect after-sales service. After more than 20 years of continuous development and innovation, it has gradually moved towards scientific, institutionalized, standardized management track. Warmly welcome people all over the world to visit, guide and negotiate business!

Staff Activity

Q: What is your company hot product?

A: Our main products include: organic fertilizer, compound fertilizer, BB fertilizer, blended fertilizer complete production line with capacity 10,000--200,000 tons/year, non-drying extrusion production line, high-humidity materials drying and fermentation equipment such as chicken manure.

Q: Are you a factory?

A: Yes,we are direct source factory,was established in 2001 year, located in Xingyang --- the hometown of machinery in Henan province, 15 kilometers from west of Zhengzhou.

Q: Whether can you provide customized product?

A: Yes, we focus on customer needs, commit to creating value for customers, provide personalized designs and products according to the actual situation.

Q: I am the new beginner of fertilizer equipment. How can i choose the most suitable machine?

A: Please let us know your raw materials type, water content, capacity (t / h) and final particle size, our engineer will design plan and make official quotation.

Q: How long is the production period of fertilizer equipment?

A: For single set fertilizer equipment, delivery time is 7 days; for complete production line, delivery time is 35 working days.

Q: How to guarantee your machine quality?

A: 100% new before leave our factory, we guarantee our machine 14 months after shipment date.

Q: Which type trade terms do you offer?

A: EXW/FOB/CFR/CIF/ are all accepted by us.

Q: Which type trade terms do you offer?

A: EXW/FOB/CFR/CIF/ are all accepted by us.

Q: What is your payment method?

A: 30% prepayment to confirm order after sign PI or SC,the rest 70% should be paid before delivery.We also accept L/C.

Q: Do you provide installation and operation training?

Yes.If you required,we can dispatch engineer to the site for guiding machine installation, At the same time train skilled workers how to operate the machine. Installer's salary is calculated separately.
